✦Power Amplifiers

DTD

Manufacturer
Nexo
Model
DTD
Code
GW-TOPJWO
Data status
Level 1 / 5
AI-parsed

❋ Specs

16
Weight
weight_kg
1.3kg
1
Dimensions
dimensions
480 x 44 x 65mm
1
Configuration
configuration
1U 19" rack
1
Frequency range
frequency_range_hz
20-20000 (mains out, +/-0.5 dB); 20-2000 (sub out, +/-0.5 dB)Hz
1
Dynamic range
dynamic_range_db
112 (mains out, unweighted); 107 (sub out, unweighted)dB
1
THD
thd
<0.001 (mains out); <0.02 (sub out)%
1
Sampling Frequency
sampling_frequency
48/96 kHz, 64-bit internal processing
1
Signal Delay Ms
signal_delay_ms
<1 (analog in to out, flat setup)ms
1
Crosstalk Db
crosstalk_db
-100 (at 1 kHz)dB
1
Analog Inputs
analog_inputs
2 electronically balanced (XLR-F / terminal block), +22 dBU max, 24-bit
1
Analog Outputs
analog_outputs
3 electronically balanced (XLR-M / terminal block), +22 dBU max, 24-bit
1
Digital Inputs
digital_inputs
AES/EBU stereo; USB audio (2ch, 48 kHz/16-bit); optional Dante (2ch, 24-bit)
1
Amplifier
amplifier
Automatic amplifier sensing; compatible with third-party amplifiers
1
Processing
processing
Crossover, parametric EQ (2x 8-band), Linear Acoustic Phase, time alignment, speaker protection (NXAMP-derived)
1
Drivers
drivers
Speaker controller for NEXO PS Series, ID Series and GeoM6
1
Power consumption
power_consumption_w
20 maxW
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
