✦Point Source / Full-Range

ID14

Manufacturer
Nexo
Model
ID14
Code
GW-CPE7QX
Data status
Level 1 / 5
AI-parsed

❋ Specs

15
Configuration
configuration
2-way passive coaxial point source
1
Drivers
drivers
1 x Coaxial Neodymium LF 4" long excursion + HF 1.4" diaphragm
1
Frequency range
frequency_range_hz
120 - 20000Hz
1
Max SPL
max_spl_db
116dB
1
Sensitivity
sensitivity_db
95dB (1W/1m)
1
Dispersion
dispersion_deg
100° x 100° or 90° x 140°
1
Nominal impedance
nominal_impedance_ohm
16Ω
1
Power
power_w
110 - 180W
1
Crossover Frequencies Hz
crossover_frequencies_hz
120, 150Hz
1
Amplifier
amplifier
NXAMP4x1mk2 Powered TDcontroller (up to 8 x ID14 per channel)
1
Weight
weight_kg
1.7kg
1
Dimensions
dimensions
130 x 130 x 120 mm (H x W x D)mm
1
Material
material
Polyurethane enclosure
1
Connectors
connectors
Touring: 2 x NL4 Speakon; Install: cable gland with 2-core cable
1
Recommended amplifier
recommended_amplifier
NEXO NXAMP4x1mk2 / NXAMP4x2mk2 / NXAMP4x4mk2 (or DTD controller + DTDAMP4x0.7 / DTDAMP4x1.3)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
NXAMP4x1mk2GW-VOLAF0NXAMP4x2mk2GW-VYNKFENXAMP4x4mk2GW-ELDARVDTDGW-TOPJWO

NEXO NXAMP4x1mk2 / NXAMP4x2mk2 / NXAMP4x4mk2 (or DTD controller + DTDAMP4x0.7 / DTDAMP4x1.3)

❋ Similar items

❋ Where to repair

Nexo · authorized service
Group Technologies (NEXO authorized distributor & service, Australia)Melbourne, AU↗MEA Reference Audio & Vision Ltd (NEXO authorized distributor & service, Cyprus)Nicosia, CY↗Acoustic Network GmbH (NEXO authorized distributor & service, Germany)Hagen, DE↗ROCK-SHOP GmbH (NEXO authorized distributor & service, Germany)Karlsruhe, DE↗Pro Musik GmbH (NEXO authorized distributor & service, Germany)Trier, DE↗Dosveinte (NEXO authorized distributor & service, Spain)Barcelona, ES↗Novelty (NEXO authorized distributor & service, France)Gennevilliers, FR↗MK PLUS (NEXO authorized distributor & service, France)Lyon, FR↗DIMMER SARL (NEXO authorized distributor & service, France)Pantin, FR↗Audiologic (NEXO authorized distributor & service, UK)Bishop's Stortford, GB↗A.C. Entertainment Technologies (NEXO authorized distributor & service, UK)Leeds, GB↗Leisuretec Distribution (NEXO authorized distributor & service, UK)Leighton Buzzard, GB↗Sound Design (NEXO authorized distributor & service, Ireland)Dublin, IE↗TEMA SRL (NEXO authorized distributor & service, Italy)Modena, IT↗JOINT RENT S.A.S. (NEXO authorized distributor & service, Italy)Ravenna, IT↗LEVEL SAS (NEXO authorized distributor & service, Italy)Treviso, IT↗PowerHouse (NEXO authorized distributor & service, Malta)Valletta, MT↗Audio-Technica Benelux (NEXO authorized distributor & service)Utrecht, NL↗Lauda Audio (NEXO authorized distributor & service, Poland)Gdańsk, PL↗Merging Select (NEXO authorized distributor & service, Portugal)Lisbon, PT↗FLY MUSIC (NEXO authorized distributor & service, Romania)Bucharest, RO↗Light and Sound Design D.O.O. (NEXO authorized distributor & service, Serbia)Belgrade, RS↗Intersonic AB (NEXO authorized distributor & service, Sweden)Stockholm, SE↗MK Light Sound d.o.o. (NEXO authorized distributor & service, Slovenia)Ljubljana, SI↗
