✦Truss: Straight / Corners

H40V Truss

Manufacturer
Prolyte
Model
H40V
Code
GW-1U8FSD
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Manufacturer
manufacturer
Prolyte
1
Series
series
H40V
1
Truss Type
truss_type
square (4-point)
1
Main chord diameter
main_chord_diameter_mm
40mm
1
Brace Diameter
brace_diameter_mm
20mm
1
Material
material
aluminium alloy 6082-T6
1
Connector type
connector_type
conical pin (Prolyte standard)
1
Outer Dimension
outer_dimension_mm
520 × 520mm
1
Standard Length
standard_length_m
0.5 / 1.0 / 1.5 / 2.0 / 2.5 / 3.0 / 4.0m
1
Weight Per Meter
weight_per_meter_kg
~5.9kg/m
1
Surface treatment
surface_treatment
natural anodised aluminium
1
Certifications
certifications
TÜV; compliant with EN 1993 / DIN 4112
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
