✦Line Arrays

Y12

Manufacturer
d&b audiotechnik
Model
Y12
Code
GW-G7KMRT
Data status
Level 1 / 5
AI-parsed

❋ Specs

19
Height
height_mm
257mm
1
Width
width_mm
630mm
1
Depth
depth_mm
375mm
1
Weight
weight_kg
20kg
1
Frequency range
frequency_range_hz
54 - 19000Hz
1
Frequency Range Cut Mode Hz
frequency_range_cut_mode_hz
100 - 19000Hz
1
Horizontal coverage
horizontal_coverage_deg
120°
1
Impedance
impedance_ohm
8Ω
1
Power Handling Rms
power_handling_rms_w
400W
1
Peak power handling
power_handling_peak_w
1600W
1
Max Spl With 10D Db
max_spl_with_10d_db
134dB
1
Max Spl With D20 30D Db
max_spl_with_d20_30d_db
137dB
1
Max Spl With D40 D80 40D Db
max_spl_with_d40_d80_40d_db
139dB
1
Splay Angle Range Degrees
splay_angle_range_degrees
0 - 14°
1
Max Cabinets In Array
max_cabinets_in_array
24units
1
Control Dispersion Down To Hz
control_dispersion_down_to_hz
500Hz
1
Material
material
Marine plywood with polyurea cabinet protection (PCP) finish
1
Connectors
connectors
2 x NLT4 F/M, optional 2 x NL4 or 2 x EP5
1
Recommended amplifier
recommended_amplifier
d&b D80 / D20 / D40
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D80GW-W0VOZ9D20GW-4ECMEVD40GW-VLG5AO

d&b D80 / D20 / D40
